TDA7294 150 W Power Amplifier

Leave a Comment
TDA Amplifier Circuit stereo 150W

The TDA8950 is a high-efficiency Class D audio power amplifier. The typical output power is 2 × 150 W with a speaker load impedance of 4 Ω. The TDA8950 is available in both HSOP24 and DBS23P power packages. The amplifier operates over a wide supply voltage range from ±12.5 V to ±40 V and features low quiescent current consumption. The TDA8950 is a two-channel audio power amplifier that uses Class D technology. For each channel, the audio input signal is converted into a digital PWM signal using an analog input stage and a PWM modulator. To drive the output power transistors, the digital PWM signal is fed to a control and handshake block and to highand low-side driver circuits. This level-shifts the low-power digital PWM signal from a logic level to a high-power PWM signal switching between the main supply lines. A 2nd-order low-pass filter converts the PWM signal to an analog audio signal that can be used to drive a loudspeaker.

TDA Amplifier Circuit
TDA Amplifier Circuit


150 watt amplifier circuit
tip142 147 amp circuit
a1941 c5198 amp circuit
tda8954 amplifier circuit
100 watts amplifier circuit diagram
12v 100w amplifier circuit
tda8950 amplifier circuit
200 watt audio amplifier circuit diagram

TDA Amplifier Circuit


Read More...

2/11/2018

Car subwoofer filter circuit

Leave a Comment
Circuit description:
Here is the circuit diagram of a simple subwoofer filter that can be operated from a 12V DC supply. Such a circuit is very useful in automobile subwoofer applications. The circuit is nothing but a low pass filter whose pass frequency can be adjusted between 60 to 160 Hz. The circuit is designed around the TL072 dual BIFET opamp IC. Out of the two opamps inside the chip, IC1A is wired as a buffer. The left and right audio inputs after mixing is fed to the input of the IC1A using the DPDT switch S1. Switch S1 is the phase control switch which can be used to make the subwoofer in phase with other speakers. When S1 is in position 2, 180 degree phase shift will be induced.POT R7 can be used for controlling the level. IC1B forms the low pass filter whose pass frequency can be controlled by adjusting the dual gang POT R13.

Circuit Features:
  • The circuit can be powered from 12V DC.
  • IC1 must be mounted on a holder.
  • S1 is a DPDT switch.
  • R13 should be a dual gang linear POT.
  • C5 and C6 must be polyester capacitors.
  • POT R13 can be used for adjusting the pass frequency.
  • POT R7 can be used for adjusting the level.
Circuit diagram:

Car subwoofer filter
Read More...

1/28/2018

22 Watt Car Subwoofer Amplifier

Leave a Comment
Circuit Description

     The stereo signals coming from the line outputs of the car radio amplifier are mixed at the input and, after the Level Control, the signal enters the buffer IC1A and can be phase reversed by means of SW1. This control can be useful to allow the subwoofer to be in phase with the loudspeakers of the existing car radio. Then, a 12dB/octave variable frequency Low Pass filter built around IC1B, Q1 and related components follows, allowing to adjust precisely the low pass frequency from 70 to 150Hz. Q2, R17 and C9 form a simple dc voltage stabilizer for the input and filter circuitry, useful to avoid positive rail interaction from the power amplifier to low level sections.
     This unit is intended to be connected to an existing car stereo amplifier, adding the often required extra "punch" to the music by driving a subwoofer. As very low frequencies are omnidirectional, a single amplifier is necessary to drive this dedicated loudspeaker. The power amplifier used is a good and cheap BTL (Bridge Tied Load) 13 pin IC made by Philips (now NXP Semiconductors) requiring a very low parts count and capable of delivering about 22W into a 4 Ohm load at the standard car battery voltage of 14.4V.

Circuit Diagram



Parts list:

  • P1_____________10K Log Potentiometer
  • P2_____________22K Dual gang Linear Potentiometer
  • R1,R4___________1K 1/4W Resistors
  • R2,R3,R5,R6____10K 1/4W Resistors
  • R7,R8_________100K 1/4W Resistors
  • R9,R10,R13_____47K 1/4W Resistors
  • R11,R12________15K 1/4W Resistors
  • R14,R15,R17____47K 1/4W Resistors
  • R16_____________6K8 1/4W Resistor
  • R18_____________1K5 1/4W Resistor
  • C1,C2,C3,C6_____4µ7 25V Electrolytic Capacitors
  • C4,C5__________68nF 63V Polyester Capacitors
  • C7_____________33nF 63V Polyester Capacitor
  • C8,C9_________220µF 25V Electrolytic Capacitors
  • C10___________470nF 63V Polyester Capacitor
  • C11___________100nF 63V Polyester Capacitor
  • C12__________2200µF 25V Electrolytic Capacitor
  • D1______________LED any color and type
  • Q1,Q2_________BC547 45V 100mA NPN Transistors
  • IC1___________TL072 Dual BIFET Op-Amp
  • IC2_________TDA1516BQ 24W BTL Car Radio Power Amplifier IC
  • SW1____________DPDT toggle or slide Switch
  • SW2____________SPST toggle or slide Switch capable of withstanding a current of at least 3A
  • J1,J2__________RCA audio input sockets
  • SPKR___________4 Ohm Woofer or two 8 Ohm Woofers wired in parallel

Technical data:

  • Output power (1KHz sinewave): 22W RMS into 4 Ohms at 14.4V supply
  • Sensitivity: 250mV input for full output
  • Frequency response: 20Hz to 70Hz -3dB with the cursor of P2 fully rotated towards R12, 20Hz to 150Hz -3dB with the cursor of P2 fully rotated towards R11
  • Total harmonic distortion: 17W RMS: 0.5% 22W RMS: 10%

mtx jackhammer subwoofer,jackhammer subwoofer 32,jackhammer subwoofer price,jackhammer subwoofer 24 inch,mtx jackhammer 15 inch subwoofer,mtx 60 inch subwoofer,jackhammer subwoofer pimp my ride,mtx jackhammer 12 inch,

Read More...

12/23/2017

200W Audio Amplifier Circuit

Leave a Comment
Circuit description:

Connecting two TDA2030 thru cheap power transistors we can create a amplifier wich can deliver a higher power. With the components value from the schematic the total amplifier gain is 32 dB. The speaker can be 2 ohm instead of 4 ohm if we use the TIP transistors. TDA 2030 is produced by SGS Ates and is a complete audio amplifier. AB class of the final amplifier cand deliver up to 14W on 4 ohm at a +-14V power supply. With a proper designed power supply this audio amplifier can output 200W.

Circuit diagram:


transistor audio amplifier circuit diagram

transistor audio amplifier circuit diagram

Part list
  • IC1, Ic2 TDA 2030
  • T1, T3 = BD 250, TIP 36
  • T2,T4 = BD 249, TIP 35
  • D1 … D4 = 1N4001


150 watt audio amplifier circuit
400w amplifier circuit diagram
200w stereo digital audio power amplifier
3055 transistor audio amplifier circuit
1000 watts amplifier circuit diagram
200 watt audio amplifier circuit diagram
4 transistor audio amplifier
transistor audio amplifier circuit diagram

Read More...

12/20/2017

Subwoofer Circuit Diagram

Leave a Comment
Circuit Descrition
The acoustic spectrum is extended by very low frequencies 20Iz and reaches as the 20000Iz in high frequencies. In the low frequencies is degraded the sense of direction. This reason us leads to the utilization speaker for the attribution of very low frequencies. The manufacture that to you we propose distinguishes these frequencies, in order to him we lead to the corresponding amplifier. The acoustic filters are met in various points in the sound systems. The knownest application they are the filters baxandal for regulating tone low and high frequencies and filters crossover where the acoustic region is separated in subareas, in order to it leads the corresponding loudspeakers. The application that to you we propose is a simple filter of region that limits the acoustic region (20-20000Hz) in the region 20-100Hz.

With the manufacture that to you we propose you can make a active filter in order to you lead a loudspeaker of very low frequencies. With this you will place one bigger speaker between the HIFI speakers of you. In order to you have a complete picture of sound you will need also the corresponding amplifier. In the entry of circuit you will connect the two exits of preamplifier or the exit of line of some preamplifier. The circuit of manufacture allocates a exit in order to is led means of circuit of force subwoofer. If for some reason you do not have space in order to you place the third speaker in space of hearing, then you can select smaller speaker. The output will depend from the type of music that you hear. If in deed you have space, then after you make a filter and remain thanked, you can him recommend in your friends or still make other same for your friends.


Circuit Diagram



In the form it appears the theoretical circuit of filter. In first glance we see three different circuits that are mainly manufactured round two operational amplifiers. This circuits constitute mixed, amplifier with variable aid and a variable filter. The manufacture end needs a circuit of catering with operational tendency of catering equal with ±12. the operational amplifiers that constitute the active elements for this circuits of are double operational type as the TL082 and NE5532. The operational these amplifiers belong in a family provided with transistor of effect of field IFET in their entries. Each member of family allocates in their circuit bipolar transistor and effect of field. This circuits can function in his high tendency, because that they use transistor of high tendency. Also they have high honor of rhythm of elevation (slew rate), low current of polarization for the entries and are influenced little by the temperature. The operational these amplifiers have breadth of area unity gain bandwidth 3MHz. A other important element for their choice is the big reject of noise, when this exists in the line of catering.

The price of reject is bigger than 80dB, their consumption is small, from 11 until 3 mA. They are internally sold in nutshell with eight pins and allocate two operational amplifiers, In the same line in nutshell 14 pins they incorporate four operational, In the trade they are sold with code TL074, TL084 and TL064, In nutshell with eight pins they are sold operational amplifiers TL061 TL071 kajTL081. In the manufacture we used the TL082 that has two operational. First operational from the TL082 it works as amplifier and mixed for the two channels, In his negative entry he exists one small mixed with two resistances. A potentiometer in this rung determines the aid of circuit. In the point this left winger and the right channel of preamplifier they are added means of two resistances. En continuity the operational strengthens signal with aid made dependent from the price that has the potentiometer.

The place of runner is proportional with the aid of circuit. The second operational amplifier is the filter of manufacture. The filter of is acoustic frequency of second class and he is made with the materials that are round the operational amplifier. The filter of is low passage with variable frequency of cutting off. This frequency can be altered and take prices from very low frequency the 30Hz or still exceed 150Hz. The frequency of cutting off of filter depends from the prices that have the elements of circuit. Altering the values of elements we can have frequency of cutting off 150Iz, 130Iz, J00Iz, 7Ïz, 6Íz even 3Íz, this prices they can be achieved with the simple rotation of double potentiometer. The circuit of filter has been made around one operational' that it has completed TL082 that is double operational amplifier. In the exit of filter we will link the plug of expense where is connected the amplifier. In the exit of circuit is presented, the limited as for the breadth of frequencies, signal that we apply in the entry of circuit.

Parts

R1 = 39 Kohm
R2 = 39 Kohm
R3 = 47 Kohm
R4 = 10 Ohm
R5 = 22 Kohm
R6 = 4,7 Kohm
R7 = 22 Kohm
R8 = 4,7 Kohm
R9 = 10 Ohm
R10 = 220 Ohm
C1 = 39 pF
C2 = 0.1 uF
C3 = 0.1 uF
C4 = 0.2 uF
C5 = 0.4 uF
C6 = 0.1 uF
C7 = 0.1 uF
IC1 = TL064

PCB and layout


In order to you make the manufacture you will need printed that appears in the form. In this you will place the materials according to the following form. The materials are enough also easy can become certain errors. With few attention however you can him avoid. If they are presented difference malfunctions, you check carefully the circuit. The circuit, as we said, is filter and it should they are used materially good precision and quality, particularly for the capacitors. The capacitors of filters will have tolerance 5%. Of course, the manufacture will also work with material of lower quality, the trial of manufacture can become with acoustic signal of generator We apply the generator in the entry of manufacture and we measure with a voltmeter the tendency in the exit of filter. If we alter the potentiometer and are altered the tendency, then all have well.

Original article sourse: diy-electronic-projects.com

subwoofer circuit diagram pdf
12v subwoofer circuit diagram
subwoofer circuit diagram free download
4558 ic subwoofer circuit
la4440 subwoofer circuit
transistor subwoofer circuit diagram
low pass subwoofer circuit diagram
5.1 subwoofer circuit diagram

Read More...

12/19/2017

100W MOSFET power amplifier

Leave a Comment
Circuit Description:
MOSFET power amplifier circuit based on IRFP240 and IRFP9240 MOSFETs is shown here. The amplifier operates from a +45/-45 V DC dual supply and can deliver 100 watt rms into an 8 ohm speaker and 160 watt rms into a 4 ohm speaker. This Hi-Fi amplifier circuit is suitable for a lot applications like general purpose amplifier, guitar amplifier, keyboard amplifier. The amplifier can be also used as a sub woofer amplifier but a subwoofer filter stage has to be added before the input stage. The amplifier has a low distortion of 0.1%, a damping factor greater than 200, input sensitivity of 1.2V and the bandwidth is from 4Hz to 4 KHz.

Circuit Features:
  • Assemble the circuit on a good quality PCB.
  • Use a +45/-45 V DC, 3A dual supply for powering the circuit.
  • Power supply voltage must not exceed +55/-55 V DC.
  • Before connecting the speaker, check the zero signal output voltage of the amplifier and in any case it should not be higher than 50mV. If it is higher than 50mV, check the circuit for any error. Replacing Q1, Q2 with another set could also solve the problem.
  • Fit Q7 and Q8 to a 2°C/W heat sink. Both Q7 and Q8 must be isolated from the heat sink using mica sheets. Heat sink mounting kits for almost all power transistors/ MOSFETs of almost all package styles are readily available in the market.
  • All resistors other than R10, R11 and R19 are 1/4 watt metal film resistors. R10 and R11 are 5W wire wound type while R19 is a 3W wire wound type.
Circuit Diagram:
100W MOSFET power amplifier
100W MOSFET power amplifier

Searches related to 100W MOSFET power amplifier
irfp250 mosfet amplifier
mosfet power amplifier circuit
200 watt mosfet amplifier circuit
12v mosfet amplifier circuit
mosfet amplifier circuit for subwoofer
mosfet power amplifier pdf
irfp240 irfp9240 amplifier
simple mosfet amplifier circuit

Read More...

300W Subwoofer Power Amplifier

Leave a Comment
This is an amplifier circuit that is formed from a transistor amplifier miraculous. This circuit is used in the speaker subwoofer with 300W maximum power on each side. To apply it, can be used in the room that is not too large, like the car. And the voltage needed between 25 to 42 Volt DC.
300W Subwoofer Power Amplifier
300W Subwoofer Power Amplifier
Searches related to 300W Subwoofer Power Amplifier
200w subwoofer amplifier circuit diagram
subwoofer circuit diagram free download
300w subwoofer amplifier circuit diagram
low pass subwoofer circuit diagram
12v subwoofer circuit diagram
500w audio amplifier circuit diagram pdf
subwoofer circuit diagram pdf
500w power amplifier circuit diagram datasheet
Read More...

12/12/2017

Mosfet Amplifier Circuit for Subwoofer 400W

Leave a Comment
Power amp 400W IRFP448 Circuit
Amplifier circuit today,We would like to show you for the MOSFET 400 watt amplifier is amplifier on my kW shares the same circuit and basic PCB layout.
The only real difference is the number of output devices to the device.
We have using The IRFP448 design while the MOSFET amplifier 14 O / P devices.
These amplifiers can be used for virtually any application that requires high performance, low use Noise, distortion and excellent sound quality. Examples would be subwoofer amplifier should FOH stage
Amplifiers, surround a canal a very powerful sound amplifier, etc.
The 400W MOSFET-amplifier has four key stages of amplification. We are looking to start any Phase appropriate detail.
The bias and buffer stage
As the name suggests All Q ,C and ZD the Bias and buffer phases. Its main goal is to provide a stable MOSFET Gates and offset voltage and the voltage buffer amplifier stage of the High Resource capacity. What would have without the phase response and the effect
Slew rate is indeed very bad. The flip side of the coin is not the extra step
Introduction of an additional dominant pole in the amplifier feedback loop.
